Automatic Plastic Box Folder Gluer HY-600AG

Automatic Plastic Box Folding Gluing Machine, Model HY-600AG



Description

  The machine is designed for the production line of mid-sized and small-sized plastic folding boxes. When the plastic sheets are indented, they will be automatically fed into machine, folded, glued, pressed, erected and ready for packing. The production rate is 5,000 to 12,000 boxes per hour.

   The machine is easy to operate, fast, efficient and gives even application of glue. It can be installed with Hot Melt Glue System or PUR glue applicator to be versatile. Scratches and friction can be avoided during the process of folding, glue applying and circling.



Application

The automatic plastic box folding gluing machine is used for gluing PVC, PET and PP plastic boxes automatically with high speed.



Technical Parameters

Model	HY-600AG
Material to be processed	PVC, PET & PP plastic
Width of the sheet	120mm----560mm
Thickness of the plastic film	0.1mm-----0.8mm
Type of adhesive	Solvent-based adhesive, hot melt adhesive, PUR adhesive, microscopic heat treatment(PP)
Line speed	0--------150m/min
Total power	5.5 KW
Overall dimension	6.0*1.2*1.35m (L*W*H)
Net weight	1.4 Ton
